AMD Opteron 6272
Published: (last update )
| Core | |
|---|---|
| Code name | Interlagos |
| Base clock | 2100 MHz |
| Turbo full / half / single | 2400 | 3000 | 3000 MHz |
| Base multiplier | 10.5× |
| Technology | 32 nm |
| Transistors | 2400 million |
| Die size | 630 mm2 |
| Density | 3.81 M / mm2 |
| Cores / threads | 16 / 16 |
| Stepping | OR-B2 |
| Cache | |
| L1 data cache | 16 × 16 kB |
| L1 inst. cache | 8 × 64 kB |
| L2 cache | 8 × 2048 kB |
| L2 cache type | On-die, full speed |
| L3 cache | 2 × 8192 kB |
| L3 cache type | On-die, 2000 MHz |
| Instructions | |
|---|---|
| Basic inst. | x86, x87, MMX(+), SSE |
| Extended inst. | SSE2, (S)SSE3 |
| Extended inst. 2 | x86-64, SSE(4.1, 4.2, 4a) |
| Extended inst. 3 | AMD-V, AES-NI, AVX |
| Extended inst. 4 | FMA4, XOP |
| Extended inst. 5 | |
| The CPU | |
| Bus type | HT, 6400 MHz, 32 bit |
| Bus bandwith | 25 600 MB/s |
| Socket | Socket G34 |
| Package | 1944 Contact LGA |
| Package size | 60 x 42.5 mm |
| Manufacture date | 36th week of 2012 |
| Voltage | 1.1 V |
| TDP | 115 W |
| Memory controller | DDR3 1600 ECC Reg. / DDR3 1600, 256 bit |
| Integrated VGA | - |
| Release date | 2011 |
