Asus MEW-AM
Published: (last update )
Note: Coppermine Celeron and Pentium III (FSB 100) supported since PCB rev. 1.02.
| Chipset | |
|---|---|
| Model | Intel 810 |
| Northbridge | 82810 |
| Southbridge | ICH |
| Bus type | SDR, 100 MHz, 64 bit |
| Bus bandwith | 800 MB/s |
| RAM type (1) | SDR 100 MHz, 64 bit |
| RAM type (2) | - |
| RAM bandwidth | 800 MB/s |
| Maximum RAM | 512 MB |
| Reg. / ECC support | no / no |
| NB PCI-E lanes | - |
| AGP | - |
| PCI support | 2.2 |
| Integrated VGA | i810 IGP with 4MB RAM |
| The board | |
|---|---|
| Socket | socket 370 |
| Supported CPUs | Celeron Mendocino |
| Fastest CPU | Celeron 533 |
| RAM slots | 2 × SDR |
| AGP | - |
| PCI-E x16, x8, x4, x1 | , -, -, -, - |
| PCI-X / PCI / ISA | -, 4, - |
| IDE | 2 × ATA 66 |
| SATA | - |
| USB / Firewire | 2 × (1.1) |
| LAN | - |
| Format | microATX (244x244) |
| Release date | 1999 |
